BCM Modular Scout Light Mount for KeyMod

The BCM Modular Scout Light Mount is an ambidextrous aluminium weapon light mount for AR-15 and M4 rifles, attaching directly to a KeyMod handguard and clamping the light body itself.

The whole buying decision is the body diameter: this mount fits lights measuring 0.825 to 0.832 in (21.0 to 21.1 mm) across the barrel, and nothing else.

Unlike a mount that presents a Picatinny stub for a light with its own rail clamp, this one grips the light body directly, which is why it sits so low and so close to the handguard. The price of that is a fixed diameter: Bravo Company USA specify a nominal 0.830 in body with a working range of 0.825 to 0.832 in (21.0 to 21.1 mm). Measure your light before ordering. A body outside that range will either not close or will not clamp.

Within that range it is a genuinely modular mount. It is fully ambidextrous, so it works at the 3 or 9 o'clock position without buying a handed version, and multiple mounting holes let you slide the light fore and aft to put the tailcap where your thumb actually falls. The body is aluminium and weighs 0.5 oz (14 g).

Why shooters choose the BCM Modular Scout Light Mount

• Clamps the light body — sits lower and tighter than a rail-and-ring arrangement
• Fully ambidextrous — 3 or 9 o'clock from the same part
• Multiple mounting holes — position the tailcap where your thumb reaches it
• 0.5 oz (14 g) aluminium body — negligible weight at the front of the rifle
• Low-profile and snag-free — nothing standing proud to catch on kit

What the BCM Modular Scout Light Mount fits

Two things have to be true. First, the handguard must be KeyMod — this mount attaches to KeyMod slots and will not fit an M-LOK or Picatinny handguard. Second, and more importantly, the light body must measure 0.825 to 0.832 in (21.0 to 21.1 mm) in diameter, a nominal 0.830 in. Bravo Company USA name the SureFire Scout Light M300 MINI, M600AA, M600 ULTRA, M600P FURY, M300V MINI and M600V as fitting, along with Streamlight tactical models including the ProTac 350 and TacPro. If your light is not on that list, measure the body before ordering rather than assuming. It suits AR-15/M4 rifles including UK straight-pull AR-15 builds. Torque the light clamp screws to 25 in-lb and the KeyMod fasteners to 30 in-lb. No light is included.

Specifications

Measure the light, then order once. Order the BCM Modular Scout Light Mount today — in stock at Xtreme Tactical Gun Parts with free tracked UK delivery in 7–10 days.
